Nres tsheb cob System Ultrasonic Sensor

Ultrasonic Sensor (built-in LED) raws li tshuab nrhiav kom tau Ultrasonic, Ultrasonic Sensor no hanged nyob nruab nrab ntawm qhov chaw nres ntsheb (ywg rau saum qab nthab los sis hauv lub cable tais) lawm mas, yuav muaj cov tsheb thiab muab ntaub ntawv real-time rau lawv PGS. 2-hauv-1 tsim, built-in...

Khoom Taw qhia

Ultrasonic Sensor (built-in LED)


Raws li siv tshuab nrhiav kom tau Ultrasonic, Ultrasonic Sensor no hanged nyob nruab nrab ntawm qhov chaw nres ntsheb (ywg rau saum qab nthab los sis hauv lub cable tais) lawm mas, yuav muaj cov tsheb thiab muab ntaub ntawv real-time rau lawv PGS.


2-hauv-1 tsim, built-in LED ua tau ib qhov taw qhia Bay

1. siab neeg: dual tias hom (av andamp; nrhiav kom tau lub tsheb)

2.anti-cuam: dua kom paub tias yuav tsum tsis txhob yuam kev

3. kim txuag: 2-hauv-1 tsim, built-in LED ua tau ib qhov taw qhia Bay

4. kim txuag: nyuaj plahaum andamp; kho (RJ45 ntsaws thiab rub cabling)

5. kim txuag: luv Circuit Court kev tiv thaiv kom tsis txhob ua

6. poj adoptability: tsim lwm yam

Kev Datasheet

Dimension	13cm(D)*6cm(H)	Yuag	0.15kg
Xim	Pem hauv ntej: Frosted dawb; Rov qab: dub	Tsev	ABS
Voltage ua hauj lwm	DC24V	Ncov tam sim no	30mA
Zaus	40kHz	Translation	andgt;-75dB
Hom kev sib txuas lus	RS485	Kis nyob deb li cas	andlt; 1000m
Nrhiav kom tau lub	andlt; 300	Nrhiav kom tau nyob deb li cas	0.5-4 m
Kub ua hauj lwm	-25 ~ 700 C	Yuam kev	±0.2 m
